ERW Welded Steel Pipe

ERW Welded Steel Pipe Manufacturer & Supplier

An ISO 9001:2008 certified company, Vishal Tube take immensure pleasure in introducing itself as one of the leading manufacturer, stockiest & exporter of high quality ERW Welded Steel Pipe, Its available with Vishal Tube in various materials such as Stainless steel Pipes & Tubes, Nickel Tubing, Monel Tubing, Inconel 600 tubing, Inconel 625 tubing, Inconel 825 tubing, Hastelloy tubing, Hastelloy c276 pipe, Carbon steel pipes & tubes and Alloy steel pipes & tubes to meet the customer ultimate requirements. We welcome small quantities. We also offer competitive pricing on small & larger quantity ERW Welded Steel Pipe.

Stainless steel pipe and tube resist corrosion and oxidation, withstand high temperatures, provide cleanliness with low maintenance costs, and won’t interact with a wide variety of materials.

Send Enquiry

ERW Welded Steel Pipe Specification

ERW STEEL PIPES/ERW CARBON STEEL PIPES

Usage: Used for low pressure liquid delivery, such as water, gas, and oil.

Process:
ERW (Electric Resistance Welded)
HFI (High Frequency Induction)
EFW(ELECTRIC FUSION WELDED TUBE)
HFW(High-Frequency Welding)

Quality Standard:
ERW HFI, EFW
GB/T3091 Welded steel pipe for low pressure liquid delivery
GB/T9711 Petroleum and natural gas industries- Steel pipe for pipelines
IS: 3589 Steel tubes for water and sewage
IS: 1978-1982? Steel tubes for use in transportation of oil; gas & Petroleum products?
BS: 1387 Steel Tubes for use for Water, Gas, Air and Steam
ASTM A53 Standard Specification for Pipe, Steel, Black and Hot-Dipped, Zinc-Coated, Welded and Seamless
DIN 2458 WELDED STEEL PIPES AND TUBES
EN10217 Welded steel tubes for pressure purposes. Technical delivery conditions. Non-alloy steel tubes with specified room temperature properties
API 5L Line Pipe
Coating Standard:
ANSI/AWWA C104/A21.4 American National Standard for Cement-Mortar Lining for Ductile-Iron Pipe and Fittings for Water
ISO 21809 Petroleum and natural gas industries -- External coatings for buried or submerged pipelines used in pipeline transportation systems
DIN 30670 Polyethylen coatings of steel pipes and fittings

Steel Grade:
BS:1387, EN10217:S185, S235,S235JR, S235 G2H, S275, S275JR, S355JRH, S355J2H, St12, St13, St14, St33, St37, St44, ST52
ASTM A 53: Gr. A, Gr B, Gr C, Gr.D
API 5L: A, B, X42, X46, X52, X56, X60, X65 X70
GB/T9711: L175, L210, L245, L290, L320, L360, L290, L320, L360, L390, L415, L450, L485, L555
GB/T3091, SY/T5037, SY/T 5040,CJ/T 3022:Q195, Q215, Q235, Q275, Q295, Q345, 08F, 08, 08AL, 08F, 10F, 10, HG5, DF08 SPHC, M8

Size:
ERW, HFI, EFW:
Outer Diameter: 6mm-610mm (1/16"-24")
Wall Thickness: 0.3mm-22mm
Length: 0.5mtr-20mtr

End: square ends (straight cut, saw cut, and torch cut). or beveled for welding, beveled,

Surface: Lightly oiled, Hot dip galvanized, Electro galvanized, Black, Bare, Varnish coating/Anti rust oil, Protective Coatings (Coal Tar Epoxy,? Fusion Bond Epoxy, 3-layers PE)

Packing:Plastic plugs in both ends, Hexagonal bundles of max. 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips, Plastic caps.
Test: Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test.
Mill Test Certificate:EN 10204/3.1B
Third party inspection:SGS, BV, Lloyds etc.

ERW Welded Steel Pipe buy at Factory Price

Specialized products: ERW Welded Steel Pipe Price List of Vishal Tube

• Spiral Welded Steel Pipe
  US $500-1000 / Ton (FOB Price)
• 304 stainless steel welded round tubes and pipe
  US $1000-5000 / Ton (FOB Price)
• welded erw steel pipe
  US $701-800 / Metric Ton (FOB Price)
• AWWA C210 Spiral Welded Pipe
  US $650 / Ton (FOB Price)
• monel 400 UNS N04400 Nickel based alloy welding pipe
  US $10-50 / Kilogram (FOB Price)
• Nickel Alloy welded Pipe ASTM B705 UNS NO 6625 nace mr0175 TUBES
  US $500-700 / Ton (FOB Price)
• monel 400 nickel alloy welded pipe
  US $20-100 / Kilogram (FOB Price)
• nickel 200 W.Nr 2.4060 Nickel alloy welding pipe
  US $10-50 / Kilogram (FOB Price)
• W.Nr 24660 nickel alloy 20 welded pipe
  US $1-20 / Kilogram (FOB Price)
• Stainless Steel Tubes
  US $2500-9500 / Ton (FOB Price)
• Stainless Steel Tube 304/316L Polished Welded Manufacturer
  US $2000-5000 / Metric Ton (FOB Price)
• welded 304 stainless steel pipe
  US $2500-3000 / Ton (FOB Price)
• stainless steel tubing ASTM A213 TP304/304L
  US $4000-20000 / Ton (FOB Price)
• 304 Stainless Steel Pipe
  US $3200-3500 / Ton (FOB Price)
• 316 304 Thin Wall Large Diameter Stainless Steel Tube
  US $1000-3000 / Ton (FOB Price)
• 304 STAINLESS STEEL TUBE
  US $2770-2800 / Tonne (FOB Price)
• Stainless Steel Tube As per ASTM A269
  US $3.93-8.89 / Kilogram (FOB Price)
• AISI best 904L stainless steel welded tube price
  US $1900-3500 / Ton (FOB Price)
• stainless steel welded tube
  US $2600-3300 / Ton (FOB Price)
• High Quality 310S 317 316L 347 310 316 304 stainless steel tube
  US $1-10 / Kilogram (FOB Price)
• Stainless Steel Tube/Stainless Steel Pipe
  US $1000-2000 / Metric Ton (FOB Price)
• ASTM A554 Welded Stainless Steel Tubes for Construction and Decoration
  US $1600-4500 / Metric Ton (FOB Price)
• ASTM 304 Stainless Steel tube
  US $3.5-6.5 / Kilogram (FOB Price)
• 201/202/304/316 Stainless Steel Tube
  US $1800-3000 / Ton (FOB Price)
• Oval Welded 304 Stainless Steel Tube
  US $1800-3200 / Ton (FOB Price)
• ASTM A269 TP304/304L Seamless Stainless Steel Tube
  US $5000-7000 / Ton (FOB Price)
• Seamless Stainless Steel Tubes
  US $5-8 / Kilogram (FOB Price)
• welded stainless steel tube
  US $4000-6500 / Ton (FOB Price)
• ASTM A672 EFW welded pipe
  US $600-800 / Ton (FOB Price)
• astm a358 321 ASTM 316l astm 304 stainless seamless steel pipe
  US $1000-4500 / Ton (FOB Price)
• astm a358 316l stainless steel pipe
  US $2000-7000 / Metric Ton (FOB Price)
• TP316 astm a358 316l stainless steel pipe
  US $3-7 / Kilogram (FOB Price)
• A358 304 Welded Stainless Steel Pipe
  US $500-1000 / Ton (FOB Price)

ERW Welded Steel Pipe Packaging

Delivery: Within 10-25days or asap if we have enough stock

Depending on the size of the diameter of the pipes & tubes these individually (large diameter ERW Welded Steel Pipe) or in bundles (small diameter ERW Welded Steel Pipe) are transported. ERW Welded Steel Pipe in bunches are taken together with metal strips or wires in the transverse direction. It is important to make sure that the strapping is very firm, so that the individual pipes can not move against each other and thereby suffer damage. Subject to transport, duration and turnover can be wrapped in eg plastic jute fabric and is provided at the bundle ends and stop points with sheet metal bundled pipes. specialty pipes shall be protected against corrosion and are usually coated or in appropriately chosen cases or wood-corrugated structures packaged. Specialty coatings, such as of PE, require padding to ensure that the protective layer is not damaged. tubes (center tubes) with sensitive inner surfaces, threads or bevel (tapered edge) are on the ends of the protection provided with caps made ​​of plastic or metal.

We pack ERW Welded Steel Pipe in a proper way to protect from moisture.

Marking of packages

Through a correct and complete marking of packaging will create the conditions to avoid misuse, accidents, wrong delivery, mass and volume losses and customs penalties. We do marking very clear and precise on ERW Welded Steel Pipe. You should contrast clearly with the package, usually it is applied in black color.

Types of Packaging:

• - Bundles (hexagonal)
• - Wooden Boxes
• - Crates (steel/wooden)
• - Special crates for U-Bend tubes with each radius separated
• - Packaging for SS 304 ASTM A312 Seamless Pipe as per customer's requirements

ERW Welded Steel Pipe uses & Application

ERW Welded Steel Pipe other available grades

Corrosion Resistant Seamless Tubing
AMS 5560 TP321 Steel Tubing
AMS 5557 TP347 Steel Tubing
AMS 5560 TP304 Seamless Steel Tubing
AMS 5562 Seamless Steel Tubing
AMS 5566 TP304 Seamless Steel Tubing
AMS 5567 Seamless Steel Tubing
AMS 5570 Seamless Steel Tubing
AMS 5571 Seamless Steel Tubing
AMS 5572 Seamless Steel Tubing
AMS 5573 TP316 Seamless Tubing
AMS 5574 TP309S Seamless Tubing
AMS 5575 Seamless Steel Tubing
AMS 5639 TP304 Seamless Tubing
AMS 5645 TP321 Seamless Tubing
AMS 5546 TP347 Seamless Tubing
AMS 5647 TP304L Seamless Tubing
AMS 5648 TP316 Seamless Tubing
ASTM A312 Seamless Pipe

Stainless Steel Grades

ERW Welded Steel Pipe other welded Pipes & Tubes

Type 304- Specialized

Type 304L- Specialized

Type 304H- Specialized

Type 310

Type 310S

Type 316 - Specialized

Type 316L- Specialized

Type 317

Type 317L

Type 321

Type 321H

Type 347

Type 347H

Type 410

Type 446

Type 904L- Specialized

More about ERW Welded Steel Pipe & its grade

Welded” can mean longitudinal seam welded tubing manufactured by an autogenous (without filler metal) fusion welding process, as opposed to tubing manufactured by other welding processes, such as solid-state processes. Welded tubing is made by forming flat products (strip, sheet or plate) into the desired shape, in this case, normally round.

Project Materials Stock List

Pipe Type	NB Sizes	Sch 5	Sch 10	Sch 40	Sch 80	Sch 160
ERW Welded Steel Pipe	1/8″
ERW Welded Steel Pipe	1/4″
ERW Welded Steel Pipe	3/8″
ERW Welded Steel Pipe	1/2″
ERW Welded Steel Pipe	3/4″
ERW Welded Steel Pipe	1″
ERW Welded Steel Pipe	1 1/4″
ERW Welded Steel Pipe	1 1/2″
ERW Welded Steel Pipe	2″
ERW Welded Steel Pipe	2 1/2″
ERW Welded Steel Pipe	3″
ERW Welded Steel Pipe	4″
ERW Welded Steel Pipe	5″
ERW Welded Steel Pipe	6″
